Product Description

• Full-color starlight

• 20 m illumination distance

• Max. 30fps@1080P

• CVI/CVBS/AHD/TVI switchable

• Fixed lens (2.8 mm;3.6 mm optional)

• IP67, 12V±30% DC

• Functions

• Full-color Starlight

• The camera adopts F1.6 large aperture lens and 1/2.8" high performance sensor

• With higher amount of absorbed light and advanced image processing algorithm, the camera presents an impressive lowlight performance with an exceptional balance between noise reduction and the blur of moving object

• Warm Supplemental lights

• With one warm supplemental LED lights, the camera is able to provide a coloful and vivid image even in total dark

• By default, the camera is set to smart light mode, in which the camera can automatically adjust

  the exposure time and light sensitivity simultaneously to avoid overexposureing of the objects in the image center

• Also, the sensitivity and intensity of the LED lights can be remotely controlled by OSD menu

• Broadcast-quality Audio

• Audio information is used as supplementary evidence in video surveillance applications

• The HDCVI camera supports audio signal transmission over coaxial cable

• In addition, it adopts unique audio processing and transmission technology that best restores source audio and eliminates noise, guaranteeing the quality and effectiveness of collected audio information

• This function is available for select models

• 4 Signals over 1 Coaxial Cable

• HDCVI technology supports 4 signals to be transmitted over 1 coaxial cable simultaneously, i.e. video, audio, data and power

• Dual-way data transmission allows the HDCVI camera to interact with the XVR, such as sending control signal or triggering alarm

• Audio input is available for some models of HDCVI cameras

• Long Distance Transmission

• HDCVI technology guarantees long-distance and real-time transmission without any loss

• It supports up to 700 m for 2MP HD video via coaxial cable, and up to 300 m via UTP cable

• Actual results verified by real-scene testing in Dahua's test laboratory

• Simplicity

• HDCVI technology inherits the born feature of simplicity from traditional analog surveillance system, making itself a best choice for investment protection

• HDCVI system can seamlessly upgrade the traditional analog system without replacing existing coaxial cabling

• The plug and play approach enables full HD video surveillance without the hassle of configuring a network

• Multiple-formats

• The camera supports multiple video formats including HDCVI, CVBS and other two common HD analog formats in the market

• The four formats can be switched over through OSD menu or by PFM820 (UTC controller)

• This feature makes the camera to be compatible with most end users’ existing HD/SD DVRs

• Protection

• The camera's outstanding reliability is unsurpassed due to its rugged design

• The camera is protected against water and dust with IP67 ranking making it suitable for indoor or outdoor environments

• With working temperature range of -40 °C to 60 °C (-40 °F to 140 °F), the camera is designed for extreme temperature environments

• Supporting ±30% input voltage tolerance, this camera suits even the mostunstable power supply conditions

• Its 4KV lightning rating provides protection against the camera and its structure from the effects of lightning

Product Specification

Brand	Dahua
Product Type	Eyeball Camera
Model	DH-HAC-HDW1239TLP-A-LED
Series	Lite Plus
Camera
Image Sensor	1/2.8 inch 2.16 Mega Pixels CMOS
Effective Pixels	1920 (H)×1080 (V), 2MP
Electronic Shutter Speed	PAL:1/25s–1/100000s NTSC:1/30s–1/100000s
Minimum Illumination	0.005Lux/F1.6, 30IRE, 0Lux white Light on
Fill Light (White Light) Distance	Distance up to 20m (65.61ft)
Fill Light On/Off Control	Auto; Manual
Fill Light Number	1
Pan/Tilt/Rotation Range	Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360°
Lens
Lens Type	Fixed-focal
Mount Type	M12
Focal Length	2.8mm/3.6mm
Max. Aperture	F1.6
Angle of View	2.8mm: 126.2°×106.0°×56.5° (diagonalxhorizontalxvertical) 3.6mm: 103.6°x86.9°x46.3° (diagonalxhorizontalxvertical)
Iris Type	Fixed iris
Close Focus Distance	2.8mm: 0.6m (1.97ft) 3.6mm: 1.2m (3.94ft)
DORI Distance	Lens	Detect	Observe	Recogniz	Identify
	2.8mm	38.6m (126.6ft)	15.4m (50.5ft)	Dahua Full Color Starlight HDCVI Eyeball Camera DH-HAC-HDW1239TLP-A-LED Title: DefaultTitle $ 87.37 $ 67.21 Please select combo product attributes The combo subtotal is $,SAVE$ Unavailable Add to Cart Buy It Now You May Also Like $ 57.01 $ 43.85 SAIFI Silky & Shine Sleep Satin Cap SF 059 MULTI $ 66.33 $ 51.02 4K (8MP) Ultra HD Outdoor Metal Security Cameras with Audio & 150ft Color Night Vision (4-Pack) $ 63.65 $ 48.96 Godox TT350N 2.4G i-TTL HSS Speedlite Flash and X2T-N trigger kit for Nikon - Bundle $ 91.00 $ 69.90 Mazam 2PCS Luggage Set TSA Lock Hard Case Silver $ 20.42 Rosslare - PX-13R - Piezoelectric Switch - 0-30 VDC - IP68 - Red $ 90.45 $ 69.58 Dreadlocks and Braids Cap M1616BLK $ 79.99 Beuchat Activ Reel 30M with line $ 87.91 $ 67.62 Photo Basics Strobelite 150W Strobe $ 69.24 $ 53.26 Acti E933 2Mp Outdoor Ir Network Mini Dome Camera $ 62.58 $ 48.14 Pure Fix 700C 60mm Wheelset ＋ Home Smart Cameras ＋ Indoor Surveillance Cameras Outdoor Security Cameras Smart Door Locks ＋ Fingerprint Smart Locks Sensors ＋ Motion Detection Sensors Window Break Sensors Lighting ＋ Smart Floodlights Wireless Systems ＋ Surveillance Wi-Fi Hubs Bluetooth Camera Sync Kits Accessories ＋ Wall Mount Alarm Panels Security System Controllers Cart ＋ Your cart is currently empty. Total: VIEW CART
